EPC-P30X6 User Manual/ 用户手册
14
2.3 Connector and Header List
Description
Part Reference
1
DCIN power connector
DCIN1
2
CPU SCOKET LGA 1151 H4
CPU1
3
SPI BIOS Flash Socket
SPI1
4
SPI Pin Header
SPI_CN1
5
CPU FAN connector
CPUFAN1
6
PWRBTN#/ RESET#/HDD LED Header
JFP1
7
DDR4 SODIMM socket A1
DIMMA1
8
DDR4 SODIMM socket B1
DIMMB1
9
Gold Finger 1
GF1
10
PCH Heatsink
HS1
11
Gold Finger 2
GF2
12
COM5 / 6 connector
COM56
13
COM3 / 4 connector
COM34
14
COM1 / 2 connector
COM12
15
RJ45 + USB3.0 stack connector
LAN3_USB56
16
RJ45 + USB3.0 stack connector
LAN2_USB34
17
RJ45 + USB3.0 stack connector
LAN1_USB12
18
HDMI1 stack connector
HDMI1
19
VGA1 stack connector
VGA1
20
PWRBTN
PWRBTN1
21
UART1/2, STAT LED
LED1
22
SATA Power Connector
SATA_PWR3
23
SATA Power Connector
SATA_PWR2
24
SATA Power Connector
SATA_PWR1
25
Buzzer
SP1
26
System Fan connector
SYSFAN1
27
SIM Card 1
SIM1
28
SIM Card 2
SIM2
29
M.2 B Key connector
M2B1
30
M.2 E Key connector
M2E1
31
AT/ATX Mode selection
PSON1
32
USB Power selection for USB78/ USB910
JUSBPWR2
33
Universal Serial Bus Port 9 / 14
USB910
34
Case Open connector
JCASE1
35
Power LED pin header
JFP2
36
I2C pin header
JFP3
37
Watchdog timer output and OBS beep
JWDT1+JOBS1
38
Universal Serial Bus 3.1 Port 7 / 8
USB78
39
CMOS battery connector
BAT1
40
Serial ATA interface connector
SATA1
41
Serial ATA interface connector
SATA3
42
Serial ATA interface connector
SATA2
43
COMS Mode selection
JCMOS1
44
8-bits General Purpose I/O pin header
GPIO1
45
8-bits General Purpose I/O pin header
GPIO2
46
Low pin count interface connector
LPC1
