PRODUCT OVERVIEW
14
The following view applies to EKI-5524SS-ST, EKI-5524SSI-ST, EKI-5524MM-ST and
EKI-5524MMI-ST.
Figure 1-7. Front View
4 Speed LED Fast Ethernet:
Amber: 100M
Off: 10M
5 ST port EKI-5524SS/EKI-5524SSI: Two SC (single mode) ports.
EKI-5524MM/EKI-5524MMI: Two SC (multi mode) ports.
Table 1-10. Front View
No. Item Description
1 System LED panel See “System LED Panel” on page 22 for further details.
2 ETH port Four RJ45 ports.
Port numbers in black are designated for port based Quality of Ser-
vice (QoS) functionality.
3 LNK/ACT LED Link activity LED.
Table 1-9. Front View (Continued)
No. Item Description
P2
P1
P-Fail
Loop
EKI-
5524SSI-ST
5524SSI-ST
3
4
5
1
2
6
LNK/ACT
LNK/ACT
TX
RX
1
2
3
4
5
