PRODUCT OVERVIEW
13
The following view applies to EKI-5524SS, EKI-5524SSI, EKI-5524MM and EKI-5524MMI.
Figure 1-6. Front View
4 Speed LED Fast Ethernet:
Amber: 100M
Off: 10M
5 ST port EKI-5525S-ST/EKI-5525SI-ST: One ST (single mode) port.
EKI-5525M-ST/EKI-5525MI-ST: One ST (multi mode) port.
Table 1-9. Front View
No. Item Description
1 System LED panel See “System LED Panel” on page 22 for further details.
2 ETH port Four RJ45 ports.
Port numbers in black are designated for port based Quality of Ser-
vice (QoS) functionality.
3 LNK/ACT LED Link activity LED.
Table 1-8. Front View (Continued)
No. Item Description
P2
P1
P-Fail
Loop
EKI-
5524SSI
5524SSI
3
4
5
1
2
6
LNK/ACT
LNK/ACT
TX
RX
1
2
3
4
5
