SmartFlex SR308
5.9.1 Status indication
There are status LEDs on the front panel to provide router status information. Each ETH
port has two additional LEDs that provide information about the port status.
Caption Color State Description
PWR Green Blinking
On
Fast blinking
The router is booting up.
The router booted up and is ready.
The router firmware is being updated.
USR Yellow — The function of this LED is user-defined.
POE Yellow
Green
On
Blinking
On
Blinking
Off
PSE: The insufficient voltage on the PWR connector.
PSE: The powered device takes too much power.
1
PD: The power supply is present on an ETH port.
PSE: A correct power supply on the PWR connector.
PSE: A device is powered via one of the ETH ports.
PD: The power supply is not present on an ETH port.
PSE: The PoE disabled in the Ethernet configuration.
SIM Green
Yellow
On (Green color)
On (Yellow color)
The first SIM card is active.
The second SIM card is active.
WAN Yellow Fades out 1x/5 s
Fades out 1x/2 s
Fades out 1x/1 s
Signal strength is good.
Signal strength is fair
2
.
Signal strength is poor
3
.
For value ranges of signal strength see Configuration
manual, chapter Mobile WAN Status.
DAT Red Blinking Cellular communication is in progress.
IN0 Green On The first binary input is active.
IN1 Green On The second binary input is active.
OUT Yellow On The binary output is active.
ETH0
ETH1
Green On
Off
Selected 100 Mbps.
Selected 10 Mbps.
ETH0
ETH1
Yellow On
Blinking
Off
The network cable is connected.
Data transmission.
The network cable is not connected.
Table 6: LED status indication
The status indication of the WAN LED is updated every 10 seconds.
1
Additionally it can indicate a device without PoE support connected on the other side of the cable. In this case
the indication is caused by low impedance (lower than 500 Ω) of the device without PoE support. This can be
solved by disabling the PoE PSE feature on the relevant ETH port in the router’s Web interface, see Configuration
manual [1].
2
Or the difference between neighbouring cells is exactly 3 dBm.
3
Or the difference between neighbouring cells is smaller than 3 dBm.
18
