13
Pin
Pin Name
Type
Description
39
GND
G
Ground connections
41
PETp0
O
PCI Express transmit data- Positive
43
PETn0
O
PCI Express transmit data- Negative
45
GND
G
Ground connections
47
REFCLKp0
I
PCI Express differential clock input- Positive
49
REFCLKn0
I
PCI Express differential clock input- Negative
51
GND
G
Ground connections
53
CLKREQ0#(3.3V)
OD
PCIe clock request
55
PEWAKE0#(3.3V)
OD
PCIe wake signal
57
GND
G
Ground connections
59
RESERVED/PERp1
NC
No Connection
61
RESERVED/PERn1
NC
No Connection
63
GND
G
Ground connections
65
RESERVED/PETp1
NC
No Connection
67
RESERVED/PETn1
NC
No Connection
69
GND
G
Ground connections
71
RESERVED/REFCLKp1
NC
No Connection
73
RESERVED/REFCLKn1
NC
No Connection
75
GND
G
Ground connections
Table 2-1 Top side pin assignment
