12
The following section illustrate signal pin-outs for the module connector.
l Top Side
Pin
Pin Name
Type
Description
1
GND
G
Ground connections
3
USB_D+
I/O
USB serial differential data Positive
5
USB_D-
I/O
USB serial differential data Negative
7
GND
G
Ground connections
9
SDIO_CLK/SYSCLK
NC
No Connection
11
SDIO_CMD
NC
No Connection
13
SDIO_DATA0
NC
No Connection
15
SDIO_DATA1
NC
No Connection
17
SDIO_DATA2
NC
No Connection
19
SDIO_DATA3
NC
No Connection
21
SDIO_WAKE#
NC
No Connection
23
SDIO_RESET#/TX_BLANKING
NC
No Connection
25
NOTCH FOR KEY E
NC
No Connection
27
NOTCH FOR KEY E
NC
No Connection
29
NOTCH FOR KEY E
NC
No Connection
31
NOTCH FOR KEY E
NC
No Connection
33
GND
G
Ground connections
35
PERp0
I
PCI Express receive data-Positive
37
PERn0
I
PCI Express receive data- Negative
