ACP-4010 User Manual 6
2.1 System Setup
The following procedures instruct users to install a backplane/motherboard, add-on
cards and disk drives into the ACP-4010. Please also refer to Appendix A, Exploded
Diagram, for the detailed parts of ACP-4010.
2.2 Removing the Top Cover
To remove the cover of ACP-4010, please proceed as below.
1. Loosen the two thumb screws on the rear of the top cover.
2. Pull the chassis top cover backwards and then lift it up
.
Figure 2.1: Removing the chassis top cover
Caution! Use caution when installing or operating the components with the chas-
sis open. Be sure to turn off the power, unplug the power cord and
ground yourself by touching the metal chassis before you handle any
components inside the machine.
