ADJ Products, LLC - www.adj.com - WiFly Bar RGBA User Manual Page 16 ADJ Products, LLC - www.adj.com - WiFly Bar RGBA User Manual Page 17
WiFly Bar RGBA ADJ RFC Operation
The ADJ RFC remote (sold seperately) has many different functions and al-
lows you to control your WiFly Bar RGBA from long distance. The ADJ RFC
remote can control your system up to 150 ft. To use the RFC you must first
activate the fixtures receiver, to activate the receiver please see the instruc-
tions on pages 13-14.
BLACkOUT - Pressing this button will blackout the fixture.
AUTO RUN - This button will run an automatic program. The built-in pro-
grams will run in a continuous loop. Press the FLASH button and use the “+”
and “-” buttons to adjust the flash speed. Press the FLASH button again to
enter Fade time and use the “+” and “-” buttons to adjust the fade speed.
PROGRAM SELECTION -
This button will activate 1 of 2 modes; Color
Select mode or Built-In Programs.
1. Press this button so that the Red LED’s flash, you are now in Color Select
mode. Use the “+” or “-” to scroll through the 15 colors. Once you have
found your color, you can press the Flash Button to activate strobing and
use the “+” or “-” to adjust the Flash rate.
2. Press this button so that the Green LED’s flash, you are now in Built-In
Program mode. Use the “+” or “-” to scroll through the built-in 22 programs.
Once you have found your desired program and you can press the SPEED
button and then use the “+” and “-” buttons to adjust the program speed.
You can press the Flash Button to activate strobing and use the “+” or “-” to
adjust the Flash rate. Press the FLASH button again to enter Fade time and
use the “+” and “-” buttons to adjust the fade speed.
FLASH - This button will activate the flash (strobe) effect. You can control
the flash speed by pressing the “+” and “-” buttons.
SPEED - Press this button and use the “+” & “-” buttons to adjust the speed
of the Auto run and Programs.
SOUND ACTIVE - This button activates sound active mode. Use the “+” or
“-” to adjust the sound sensitivity. Press the FLASH button to activate flash
mode and use the “+” or “-” to adjust the flash rate.
R G B W/A - Press either one of these buttons and the press the “+” or “-”
to adjust the brightness. Press the FLASH button to activate flash mode and
use the “+” or “-” to adjust the flash rate.
“+” and “-” - Use these buttons to adjust the flash rate, speed of the Auto
Run and Program, sound sensitivity, and color select.
WiFly Bar RGBA WiFly Set Up
WiFly Bar RGBA WiFly Master-Slave Set Up
With this feature you are able to control the unit with DMX without the need
of XLR cables. Your DMX controller must be connected to a ADJ WiFly
TransCeiver to use this function. You are able to communicate up to 400 feet
(open line of sight)
NOTE: The ADJ RFC control must be set to OFF to use this function.
See pages 13-14 to turn OFF ADJ RFC.
1. Turn on the WiFly function using the WiFly On/Off switch and set the
antenna to either a up position or down position.
2. Follow the instructions on page 14 to set the Wireless address. The
address must match the address set on the WiFly Transceiver.
3. After you have set the WiFly address, follow the DMX instructions on
pages 12-13 to select your desired DMX Channel mode and set your
DMX address.
4. Apply power to the ADJ WiFly Transceiver. The fixture must be set up
first before you apply power to WiFly Transceiver.
5. If everything is set up properly and the fixture is receiving a Wireless
signal, Wireless status LED next to LED screen will glow green.
Note: If the sync does not work, switch the WiFly power off then on again.
This feature will let you link units to run in a master-slave mode without the
use of XLR cables.
NOTE: The ADJ RFC control must be set to OFF on all the units to use
this function. See pages 13-14 to turn OFF ADJ RFC.
1. Follow the instructions on page 14 to set the Wireless address. The
addresses on each fixture must be the same.
2. After you have set the WiFly address, select your master unit and set
your desired operating mode.
3. Put the antenna in either a up position or down position then turn the
WiFly On, using the WiFly power switch.
Note: All antennas must be in the same position, they must either be all up
or all down, but never at an angle.
4. For the Slave units, put the unit in Slave mode. See page 15 Master-
Slave configuration when setting the unit as a Slave. Then switch ON the
WiFly power switch.
5. If everything is set up correctly, the Master units WiFly status LED will
glow orange, and the slave units Wireless status LED will glow green.
NOTE: If they do not sync up master-slave, switch the Master fixtures
WiFly power switch off then on again.
