American DJ® - www.americandj.com - Vizi Scan LED PRO Instruction Manual Page 37 American DJ® - www.americandj.com - Vizi Scan LED PRO Instruction Manual Page 38

Operating Modes: The Vizi Scan LED PRO can operate in three

different modes. This next section will detail the differences in

the operating modes.

• Sound Active mode -

The unit will react to sound, chasing through the built-in programs.

• Auto mode -

The unit will run the internal program without the need of sound.

• DMX control mode -

This function will allow you to control each individual fixtures traits

with a standard DMX-512 controller such as the Elation® Show

Designer.

™

Universal DMX Control: This function allows you to use a uni-

versal DMX-512 controller such as the Elation® DMX Operator™

or Elation® Show Designer™ to control mirror movement, the color

wheel, gobo wheel, prism, pan/tilt speed, shutter (strobe), and much

more. A DMX controller allows you to create unique programs tailored

to your individual needs.

1. The Vizi Scan LED PRO has a 12 channel DMX mode and 14

channel DMX mode. To select your desired DMX mode please

see page 24 “FINE” menu See pages 40-47 for detailed descrip-

tion of the DMX traits.

2. To control your fixture in DMX mode, follow the set-up procedures

on pages 12-14 as well as the set-up specifications that are

included with your DMX controller.

3. Use the controller’s faders to control the various DMX fixture traits.

4. This will allow you to create your own programs.

5. Follow the instruction on page 19 to set the DMX address.

6. For longer cable runs (more than a 100 feet) use a terminator on

the last fixture.

7. For help operating in DMX mode consult the manual included

with your DMX controller.

Stand-Alone Operation (Sound Active or Auto Program): This

mode allows a single unit to either run to the beat of the music or run

the Auto Program.

1. Access the main menu.

2. Tap the UP button until “PLAY” is displayed, and Press ENTER.

Vizi Scan LED PRO Operation

ing) or there is a stepper motor failure (defective motor or a

defective motor IC drive on the main PCB).

07Er – GOBO ROTATING error:

This message will appear after a xture reset, if the magnetic-

indexing circuit malfunctions (sensor failed or magnet is miss-

ing) or there is a stepper motor failure (defective motor or a

defective motor IC drive on the main PCB).

08Er – PRISM error:

This message will appear after a xture reset, if the magnetic-

indexing circuit malfunctions (sensor failed or magnet is miss-

ing) or there is a stepper motor failure (defective motor or a

defective motor IC drive on the main PCB).

10Er – FOCUS error:

This message will appear after a xture reset, if the magnetic-

indexing circuit malfunctions (sensor failed or magnet is miss-

ing) or there is a stepper motor failure (defective motor or a

defective motor IC drive on the main PCB).

Vizi Scan LED PRO Error Codes
