American DJ® - www.americandj.com - Vizi Scan LED PRO Instruction Manual Page 30American DJ® - www.americandj.com - Vizi Scan LED PRO Instruction Manual Page 29

or “AUTO”.

4. Press ENTER to conrm your selection.

5. Press MODE/ESC to return to the main menu.

HIBE - With this function you can make the unit automati-

cally shut down the LED and stepping motors. The default

setting for this is 15 mins. After 15 mins if the unit is not

receiving a DMX signal, the unit will automatically shut

down the LED and motors. This feature lengthens the life of

the LED and motors. The shut down time can be adjusted

between OFF (no shut down) or 1 - 99 minutes. Once the

LED and motors are shut down, it will reset itself when it

receives a DMX signal. When the function is set to OFF, the

LED and motors will not shut down until power is cut.

1. Access the main menu by pressing MODE/ESC button.

2. Tap the UP button until “HIBE” is displayed, press ENTER.

3. Press the UP or DOWN buttons to adjust the shut down time.

4. Press ENTER to conrm your selection.

5. Press MODE/ESC to return to the main menu.

VER - Use this function to display the Software version of

the unit.

1. Access the main menu.

2. Tap the UP button until “SPEC” is displayed, press ENTER.

3. Tap the UP button until “VER” is displayed, press ENTER.

4. The display will show “V-X.X”, “X.X” stands for the version

number, such as the display may show “V-1.0”, “V-9.9” etc.

5. Press the MODE/ESC button to exit.

Vizi Scan LED PRO System Menu Vizi Scan LED PRO System Menu

ADJU - Use this function is used to make sure all motors

are aligned and to adjust any motors that are not.

1. Access the main menu.

2. Tap the UP button until “SPEC” is displayed, press ENTER.

3. Tap the UP button until “ADJU” is displayed, press ENTER.

4. Tap the UP button until “CODE” is displayed, press ENTER.

5. The display will show “CXXX”, were as “XXX” represents the

calibration password. The calibration password is “C050.” Use

the UP or DOWN buttons to enter the proper password.

6. Once the proper password is entered the display will read

“CHXX”, were as “XX” represents the xture channel number.

7. Select the desired channel to be calibrated by pressing the

UP or DOWN buttons and then ENTER to conrm.

8. The display will then read “XXXX”, were “XXXX” stands for

the calibrate values.

9. Adjust the desired calibration value between –128 and 127

by pressing the UP and DOWN. As you scroll up and down

through the calibration values you will

notice slight changes in the wheel or motor you are attempting

to calibrate.

10. Once you reach your desired calibration press ENTER to

conrm and lock in your calibration.

11. Once you are completely nished press MODE/ESC to

return to the main menu.
