Vizi Roller Beam 2R System Menu

3. Use the UP or DOWN buttons to scroll through the 3 DMX Channel

Modes.

Standard Mode - This is 13 Channel Mode.

Basic Mode - This is 11 Channel Mode.

Extended Mode - This is 18 Channel Mode.

4. Press the MODE/ESC button once to return to the “User Mode

Set” menu. Use the UP or DOWN buttons to scroll through the Edit

modes. Press ENTER to select any of the Edit modes.

Edit User Mode – This function allows the user to make the actual

changes in the user dened modes that are created in the previous

function.

EDIT PROGRAM: - The xture comes equipped with a built-in DMX

recorder that allows custom programs to be installed and recalled

directly from the xture’s control board. Programs can be created and

stored using the xture’s control board or by using an external DMX

controller.

Select Program – This function allows the user to select one of ten

of the user dened built-in programs. This program is then accessed

in “Function Mode” under “Program Run.”

Edit Program – This function allows the user to edit the internal built-

in programs.

Edit Scenes – This function allows the user to edit or dene the

actual scenes that are stored in the user dened built-in programs

that are accessed in the previous step.

Rec Controller - The Vizi Roller Beam 2R features an integrated DMX

recorder. Preprogrammed scenes can be transmitted to the xture via

any DMX compliant controller. This function allows those scenes to

be stored in to the xture’s built-in memory and

then subsequently used to create the user-dened programs.

Vizi Roller Beam 2R Error Codes

When power is applied, the unit will automatically enter a

“reset/test” mode. This mode brings all the internal motors to a

home position. If there is an internal problem with one or more

of the motors an error code will ash in the display in the form

of “XXer”, “XX” will represent a function number. For example,

when the display shows “03Er,” it means there is some type of

error with the channel 3 motor. If there are multiple errors during

the start-up process they will all ash in the display. For exam-

ple: if the xtures has errors on channel 1 and channel 3 all at

the same time, you will see the error message ash “01Er”, and

“03Er repeated 5 times.

If an error does occur during the initial start-up procedure the

xture will self-generate a second reset signal and try to realign

all the motors and correct the errors, if the errors persist after a

second attempt a third attempt will be made.

If after a third attempt all the errors have not been corrected the

xture will make the following determinations:

1) 3 or more errors - The xture cannot function properly with

three or more errors therefore the xture will place itself in a

stand-by mode until subsequent repairs can be made.

2) Less than 3 errors - If the xture has less than 3 errors, there-

fore most other functions will work properly. The xture will

attempt to operate normally until the errors can be corrected by

a technician. The errors in question will remain ashing in the

display as a reminder of internal errors.

03Er – TILT movement error:

This message will appear after a xture reset, if the tilt mag-

netic-indexing circuit malfunctions (sensor failed or magnet is

missing) or there is a stepper motor failure (defective motor or a

defective motor IC drive on the main PCB).

05Er – COLOR WHEEL error:

This message will appear after a xture reset, if the head’s mag-

netic-indexing circuit malfunctions (sensor failed or magnet is
