ADJ Products, LLC - www.adj.com - Vizi Roller Beam 2R Instruction Manual Page 35ADJ Products, LLC - www.adj.com - Vizi Roller Beam 2R Instruction Manual Page 34

Vizi Roller Beam 2R System Menu

press ENTER.

2. Press the UP or DOWN buttons until “Reset Gobos” is displayed,

press ENTER.

3. Press ENTER to conrm your selection or press MODE/ESC to

exit.

Reset Shutter - With this function you can reset the shutter motor.

1. Press the MODE/ESC button to access the main menu. Press the

UP or DOWN buttons so that “Reset Function” is highlighted, then

press ENTER.

2. Press the UP or DOWN buttons until “Reset Shutter” is displayed,

press ENTER.

3. Press ENTER to conrm your selection or press MODE/ESC to

exit.

Reset Others - With this function you can reset all other motors.

1. Press the MODE/ESC button to access the main menu. Press the

UP or DOWN buttons so that “Reset Function” is highlighted, then

press ENTER.

2. Press the UP or DOWN buttons until “Reset Others” is displayed,

press ENTER.

3. Press ENTER to conrm your selection or press MODE/ESC to

exit.

EFFECT ADJUST

Test Channel - With this function you can test/correct each channel

function.

1. Press the MODE/ESC button to access the main menu. Press the

UP or DOWN buttons so that “Eect Adjust” is highlighted, then

press ENTER.

2. Press the UP or DOWN buttons until “Test Channel” is displayed,

press ENTER.

3. Use the UP or DOWN buttons to scroll through the various chan-

nels.

4. Press ENTER or press MODE/ESC to exit.

Manual Control - With this function you can easily adjust the lamp.

All eects will be canceled, the shutter will open and output intensity

will be 100%. With the individual functions you can focus the light on

at surface (a wall) and nely adjust the lamp.

1. Press the MODE/ESC button to access the main menu. Press the

UP or DOWN buttons so that “Eect Adjust” is highlighted, then

press ENTER.

2. Press the UP or DOWN buttons until “Manual Control” is dis-

played, press ENTER.

3. Use the UP or DOWN buttons to scroll through the various func-

tions. Press ENTER when you nd the function you would like to

adjust.

4. Press ENTER or press MODE/ESC to exit.

Calibration - With this function you can calibrate and adjust the

eects wheels to their correct positions. The Calibration password

050.

1. Press the MODE/ESC button to access the main menu. Press the

UP or DOWN buttons so that “Eect Adjust” is highlighted, then

press ENTER.

2. Press the UP or DOWN buttons until “Calibration” is displayed,

press ENTER.

3. “XXXX” will be displayed. The password is 050.

4. Press ENTER to conrm or press MODE/ESC to exit.

USER MODE SET

User Mode -

1. Press the MODE/ESC button to access the main menu. Press the

UP or DOWN buttons so that “User Mode Set” is highlighted, then

press ENTER.

2. Press the UP or DOWN buttons until “User Mode” is displayed,

press ENTER.
