American DJ® - www.americandj.com - Vizi LED Spot - Instruction Manual - Page 14American DJ® - www.americandj.com - Vizi LED Spot - Instruction Manual - Page 13

5-Pin XLR DMX Connectors.

Some manufactures use 5-pin DMX-

512 data cables for DATA transmission in place of 3-pin. 5-pin DMX

xtures may be implemented in a 3-pin DMX line. When inserting stan-

dard 5-pin data cables in to a 3-pin line a cable adaptor must be used,

these adaptors are readily available at most electric stores. The chart

below details a proper cable conversion.

Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)

Pin 1

Pin 5 - Do Not Use

Pin 4 - Do Not Use

Pin 3

Pin 2

Pin 1

Pin 3

Pin 2

Not Used

Data True (+ signal)

Data Compliment (- signal)

Ground/Shield

3-Pin XLR to 5-Pin XLR Conversion

Vizi LED Spot Set Up Vizi LED Spot System Menu

Control board show menu of VIZI LED SPOT

ADDR

AXXX A001

Indicate the staring DMX address

A001 also is the setting for slave

TEST

T-01~T-XX

Automatically test the function

RUN

MSTR/ALON

Runs fixture as “master” or “alone” for auto

AUDI

MSTR/ALON

Runs fixture as “master” or “alone” for

audio

PLAY

AUTO

Clos/Hold/Auto/Audi

No DMX Status

ALL

Reset all motors and returns fixture to home

SCAN

Reset only motors for pan/tilt

COLR

Reset only motors for colors

GOBO

Reset only motors for gobo and rotation

RESE

OTHR

Reset other motors

LIFE

0000~9999

Displays the total fixture running time

TIME

CLMP

Clear lamp running time

RPAN

ON/OFF

Reverses the pan movements

RTLT

ON/OFF

Reverses the tilt movements

FINE

ON/OFF

Switch 16 bit/8 bit

DEGR

540/630

Pan degree select

MIC

M-XX M-70

Mic sensitivity

VALU

D–XX D-00 (DXXX)

Display the DMX512 value of each channel

D ON

ON/OFF

Display turn off after 2mins

FLIP

ON/OFF

This function will reverse the display 180

DISP

LOCK

ON/OFF

Key lock

RDMX

ON/OFF

Change DMX address via external controller

SPOT

ON/OFF

Lamp optimization

DFSE

ON/OFF

Resets all the fixture functions to default

FEED

ON/OFF

Pan/tilt feedback (error correction) on/off

SPEE

SP-1/SP-2

Movement Mode Select

FANS

AUTO/HIGH/LOW

Fan’s mode select

HIBE

OFF/1-99M 15M

Stand by mode

VER

V1.0~V9.9

Software version

CODE

CXXX

Fixture code *code is “C050”

SPEC

ADJU

CH01~CHXX

XXXX(-128~127)

Motor Fix

SEPR

AUTO

IP01~IP07

Select program to be edit

STEP

S–01 ~S–48

Set the amount of your program

C–01~C–XX

XXX(0~255)

Edit the channels of each scene

TIME

T XXX(001~999)

Time for each scene

SCXX

CEDT

ON/OFF

Edit program via controller

REC.

RE.XX

Auto Save

EDIT

RUN

ON/OFF

Program test
