ADJ Products, LLC ! ww.adj.com ! VIZI CMY 16RX User Instructions Page 14
!
5-Pin
XLR DMX
Connectors:
Some manufactures use 5-pin DMX-512 data cables
for DATA transmission in place of 3-pin. 5-pin DMX fixtures may be implemented
in a 3-pin DMX line. When inserting standard 5-pin data cables in to a 3-pin line a
cable adaptor must be used, these adaptors are readily available at most electric
stores. The chart below details a proper cable conversion.
3-Pin XLR to 5-Pin XLR Conversion
Conductor
3-Pin XLR Female (Out)
5-Pin XLR Male (In)
Ground/Shield
Pin 1
Pin 1
Data Compliment
(- signal)
Pin 2
Pin 2
Data True
(+ signal)
Pin 3
Pin 3
Not
Used
Pin
4 - Do
Not
Use
Not
Used
Pin
5 - Do
Not
Use
Universal DMX Control: This function allows you to use a universal DMX-512
controller. A DMX controller allows you to create unique programs tailored to your
individual needs.
1. The Vizi CMY 16RX has a 2 DMX channel modes (22 and 24 channels).
See pages 16-24 for detailed description of the DMX traits.
2. To control your fixture in DMX mode, follow the set-up procedures on
pages 14, 25-27 as well as the set-up specifications that are included with
your DMX controller.
3. Follow the instructions on page 26 to select your desired DMX addr
ess.
4. Use the controller’s faders to control the various DMX fixture traits.
5. For longer cable runs (more than a 100 feet) use a terminator on the last
fixture.
6. For help operating in DMX mode consult the manual included with your
DMX controller.
VIZI CMY 16RX
DMX Setup
