DRIVER OUTPUT LIMITATIONS
There is a limitation to how many pixels can be controlled by each driver output port, which in turn
determines the maximum number of lighting xtures that can be controlled by a single output or
driver.
The values listed in the following tables for number of xtures per driver port/driver unit are repre-
sentative of the maximum number of xtures that can be connected if the xtures used are all of the
same model type, with individual pixel control.
For example, if you connect only Pixie Strip 30s to the driver, and operate the driver in Kling-Net
mode, you can connect up to 34 units of that model type to each driver port. This is dened by the
fact that each driver port can handle a maximum of 1020 pixels, and each Pixie Strip 30 xture is
made up of 30 pixels. Therefore, you have 1020 pixels per driver port, divided by 30 pixels per x-
ture, which equals 34 xtures per driver port.
It is possible to mix and match Pixie Strip model types that are attached to a single driver port. In
this case, the important thing to keep in mind is the maximum number of pixels per driver port.
As long as this value is not exceeded, any combination of Pixie Strip 30s, 60s, and 120s may be
used.
PIXIE STRIP 30/60/120
MODEL
TOTAL
PIXELS
TOTAL
CONTROL
CHAN.
KLING-NET
MAX PIXELS PER PORT = 1020
MAX PIXELS PER DRIVER = 2040
MAX
FIXTURES per
DRIVER PORT
MAX
PIXELS
per
DRIVER
PORT
MAX
FIXTURES
per
DRIVER UNIT
MAX
PIXELS
per
DRIVER
UNIT
Pixie Strip 30 30 90 34 1020 68 2040
Pixie Strip 60 60 180 17 1020 34 2040
Pixie Strip 120 120 360 8 960 16 1920
MODEL
TOTAL
PIXELS
TOTAL
CONTROL
CHAN.
ARTNET / sACN
MAX PIXELS PER PORT = 170
MAX PIXELS PER DRIVER = 340
MAX
FIXTURES per
DRIVER PORT
MAX
PIXELS
per
DRIVER
PORT
MAX
FIXTURES
per
DRIVER UNIT
MAX
PIXELS
per
DRIVER
UNIT
Pixie Strip 30 30 90 5 150 10 300
Pixie Strip 60 60 180 2 120 4 240
Pixie Strip 120 120 360 1 120 2 240
