ADJ Products, LLC - www.adj.com - Monster Fun Instruction Manual Page 9ADJ Products, LLC - www.adj.com - Monster Fun Instruction Manual Page 8
5-Pin XLR DMX Connectors.
Some manufactures use 5-pin DMX-
512 data cables for DATA transmission in place of 3-pin. 5-pin DMX
xtures may be implemented in a 3-pin DMX line. When inserting stan-
dard 5-pin data cables in to a 3-pin line a cable adaptor must be used,
these adaptors are readily available at most electric stores. The chart
below details a proper cable conversion.
Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)
Pin 1
Pin 5 - Do Not Use
Pin 4 - Do Not Use
Pin 3
Pin 2
Pin 1
Pin 3
Pin 2
Not Used
Not Used
Data True (+ signal)
Data Compliment (- signal)
Ground/Shield
3-Pin XLR to 5-Pin XLR Conversion
Monster Fun Set Up Monster Fun System Menu Chart
DMX Address
Sound Sense
Show Mode
Slave Mode
DMX State
Sound State
Back Light
Auto Test
Fixture Time
Firmware Version
MENU
001
0
Show 0
Show 1
Show 12
Master
Master Slave
Last State
On
Slave 1
Blackout
Slave 2
Off
On
Off
512
100
