ADJ Products, LLC - www.adj.com - Illusion Dotz 3.3 Instruction Manual Page 28 ADJ Products, LLC - www.adj.com - Illusion Dotz 3.3 Instruction Manual Page 29

Illusion Dotz 3.3 System Menu

ERROR INFO - In this menu you are able to reset the error message.

1. Press the MODE button to access the main menu. Press the UP

or DOWN buttons so that “Information” is highlighted, then press

ENTER.

2. Press the UP or DOWN buttons until “Error Info” is displayed,

press ENTER.

3. Use the UP or DOWN buttons to nd the error message that needs

to be cleared.

4. Press ENTER or press MODE to exit.

MODEL INFO - In this menu you are able to see the lamps model

information.

1. Press the MODE button to access the main menu. Press the UP

or DOWN buttons so that “Information” is highlighted, then press

ENTER.

2. Press the UP or DOWN buttons until “Model Info” is displayed,

press ENTER.

3. “XXXX” will now be displayed. “XXXX” represents the model infor-

mation.

4. Press MODE to exit.

SOFTWARE VERSION - This will allow you to see the software ver-

sion of each IC.

1. Press the MODE button to access the main menu. Press the UP

or DOWN buttons so that “Information” is highlighted, then press

ENTER.

2. Press the UP or DOWN buttons until “Software Version” is dis-

played, press ENTER.

3. Use the UP or DOWN buttons to scroll through each IC and see

the software version.

4. Press MODE to exit.

Illusion Dotz 3.3 System Menu

TEST

RESET MOTORS - With this function you can reset the Pan & Tilt

motors.

1. Press the MODE button to access the main menu. Press the UP or

DOWN buttons so that “Test” is highlighted, then press ENTER.

2. Press the UP or DOWN buttons until “Reset Motor” is displayed,

press ENTER.

3. Press ENTER to reset or press MODE to exit.

TEST CHANNEL - With this function you can test/correct each chan-

nel function.

1. Press the MODE button to access the main menu. Press the UP or

DOWN buttons so that “Test” is highlighted, then press ENTER.

2. Press the UP or DOWN buttons until “Test Channel” is displayed,

press ENTER.

3. Use the UP or DOWN buttons to scroll through the various chan-

nels.

4. Press ENTER or press MODE to exit.

PANEL CTRL. - With this function you can easily adjust the lamp. All

eects will be canceled, the shutter will open and output intensity will

be 100%. With the individual functions you can focus the light on at

surface (a wall) and nely adjust the lamp.

1. Press the MODE button to access the main menu. Press the UP or

DOWN buttons so that “Test” is highlighted, then press ENTER.

2. Press the UP or DOWN buttons until “Panel Ctrl.” is displayed,

press ENTER.

3. Use the UP or DOWN buttons to scroll through the various func-

tions. Press ENTER when you nd the function you would like to

adjust.

4. Press ENTER or press MODE to exit.

CALIBRATION - With this function you can calibrate and adjust the

eects wheels to their correct positions. The Calibration password
