©American DJ Supply® - www.americandj.com - FREQ 16 Strobe Instruction Manual Page 9 ©American DJ Supply® - www.americandj.com - FREQ 16 Strobe Instruction Manual Page 10

FREQ 16 Strobe System Menu

SHND: SH 0 - SH 12 - Show modes 0 - 12 & Manual

show. Show mode can run with or without sound active mode

on. Manual show is used in conjunction with knobs located

on the rear of the unit. NOTE: When running the fixture as a

single fixture, it must be set to the Master setting.

See page 15 for Master setting.

1. Press the MENU button until “SHND” is displayed, press

ENTER.

2. “SH X” will now be displayed, “X” representing a number

between 0-12 or “MANU” will be displayed. Shows 1-12 are

preset shows, while “SH 0” is random show. “MANU” is Manual

mode, in this mode you adjust the dimmer and strobe to your

desire using the knobs located on the rear of the unit. Press the

UP or DOWN buttons to nd your desired show.

3. Once you have found your desired show press ENTER, and

then press and hold the MENU button for at least 3 seconds to

conrm.

MANU - In this mode you can manually control the dimmer

and strobe rate. Unlike the Manual show located under the

Show Mode submenu, this Manual mode is not used with

the knobs located on the rear of the unit.

1. Press the MENU button until “MANU” is displayed, press

ENTER.

2. Either “DIMM” or “STRO” will now be displayed. Press the UP

or DOWN buttons to switch between either setting.

3. When you have decided on what setting you would like to

adjust rst, press the ENTER button. Use the UP and DOWN

buttons to make adjustments. Once you have made your desired

adjustments press ENTER.

4. Once you have nished with your adjustments DO NOT leave

this function. If you press the MENU button, all adjustments will

FREQ 16 Strobe System Menu

be lost and you will have to start over.

SOUN - In this submenu you can activate sound active

mode. NOTE: When running the fixture as a single fixture, it

must be set to the Master setting.

See page 15 for Master setting.

1. Press the MENU button until “SOUN” is displayed, press

ENTER.

2. Either “ON” or “OFF” will now be displayed. Press the UP or

DOWN buttons to select one or the other.

3. When you have made your selection, press the ENTER, and

then press and hold the MENU button for at least 3 seconds to

conrm.

SENS - Sound sensitivity control.

1. Press the MENU button until “SENS” is displayed, press ENTER.

2. The display will show a number between 0-100. Press the UP or

DOWN buttons to adjust the sound sensitivity. 0 being the least sensi-

tive and 100 the most sensitive.

3. Press the ENTER, and then press and hold the MENU button for at

least 3 seconds to conrm.

BLND - In this submenu you can activate blackout

1. Press the MENU button until “BLND” is displayed, press

ENTER.

2. Either “YES” or “NO” will now be displayed. Press the UP or

DOWN buttons to select one or the other.

3. Press ENTER to conrm your selection.
