ADJ Products, LLC - www.adj.com - 3 Sixty 2R Instruction Manual Page 56 ADJ Products, LLC - www.adj.com - 3 Sixty 2R Instruction Manual Page 57
3 Sixty 2R 32 Channel DMX Mode
Channel Value Function
1 0 - 255 PAN MOVEMENT 8bit (540° or 630°)
2 0 - 255 PAN FINE 16bit
3 0 - 255 LEFT TILT MOVEMENT 8bit
4 0 - 255 LEFT TILT FINE 16bit
5 0 - 255 RIGHT TILT MOVEMENT 8bit
6 0 - 255 RIGHT TILT FINE 16bit
7 LEFT COLOR WHEEL
0 - 8 OPEN
9 - 17 COLOR 1
18 - 26 COLOR 2
27 - 35 COLOR 3
36 - 44 COLOR 4
45 - 53 COLOR 5
54 - 62 COLOR 6
63 - 71 COLOR 7
72 - 80 COLOR 8
81 - 89 COLOR 9
90 - 98 COLOR 10
99 - 107 COLOR 11
108 - 116 COLOR 12
117 - 127 COLOR 13
128 - 189 FORWARD RAINBOW EFFECT
FAST - SLOW
190 - 193 NO ROTATION
194 - 255 BACKWARDS RAINBOW EFFECT
SLOW - FAST
8 LEFT COLOR WHEEL FINE
0 - 255 COLOR WHEEL CHANGE FINE
9 RIGHT COLOR WHEEL
0 - 8 OPEN
9 - 17 COLOR 1
18 - 26 COLOR 2
27 - 35 COLOR 3
3 Sixty 2R 24 Channel DMX Mode
Channel Value Function
22 RIGHT TILT CONTINUOUS ROTATION
0 - 127 NO FUNCTION
128 - 189 FORWARDS ROTATION FAST-SLOW
190 - 193 NO FUNCTION
194 - 255 BACKWARDS ROTATION SLOW-FAST
23 PAN/TILT MOVEMENT SPEED
0 - 225 MAX TO MIN. SPEED
226 - 235 BLACKOUT BY MOVEMENT
236 - 245 BLACKOUT BY WHEEL CHANGING
246 - 255 NO FUNCTION
24 LAMP ON/OFF, RESET & PROGRAMS
0 - 19 COLOR CHANGE NORMAL
20 - 29 COLOR CHANGE TO ANY POSITION
30 - 39 COLOR & GOBO CHANGE TO ANY
POSITION
40 - 59 LAMP ON
60 - 79 LAMP OFF
80 - 84 ALL MOTOR RESET
85 - 87 SCAN MOTOR RESET
88 - 90 COLOR MOTOR RESET
91 - 93 GOBO MOTOR RESET
94 - 96 SHUTTER/DIMMER MOTOR RESET
97 - 99 OTHER MOTOR RESET
100 - 119 INTERNAL PROGRAM 1
120 - 139 INTERNAL PROGRAM 2
140 - 159 INTERNAL PROGRAM 3
160 - 179 INTERNAL PROGRAM 4
180 - 199 INTERNAL PROGRAM 5
200 - 219 INTERNAL PROGRAM 6
220 - 239 INTERNAL PROGRAM 7
240 - 255 SOUND ACTIVE PROGRAM
The pan degree can be changed between 540° and 630°. See
page 28 to change the pan degree.
