ADJ Products, LLC - www.adj.com - 3 Sixty 2R Instruction Manual Page 55ADJ Products, LLC - www.adj.com - 3 Sixty 2R Instruction Manual Page 54
3 Sixty 2R 24 Channel DMX Mode
Channel Value Function
15 LEFT SHUTTER & STROBE
0 - 31 SHUTTER CLOSED
32 - 63 SHUTTER OPEN
64 - 95 STROBING SLOW - FAST
96 - 127 SHUTTER OPEN
128 - 159 PULSE EFFECT IN SEQUENCES
160 - 191 SHUTTER OPEN
192 - 223 RANDOM STROBE SLOW - FAST
224 - 255 SHUTTER OPEN
16 0 - 255 LEFT MASTER DIMMER 0% - 100%
17 RIGHT SHUTTER & STROBE
0 - 31 SHUTTER CLOSED
32 - 63 SHUTTER OPEN
64 - 95 STROBING SLOW - FAST
96 - 127 SHUTTER OPEN
128 - 159 PULSE EFFECT IN SEQUENCES
160 - 191 SHUTTER OPEN
192 - 223 RANDOM STROBE SLOW - FAST
224 - 255 SHUTTER OPEN
18 0 - 255 RIGHT MASTER DIMMER 0% - 100%
19 TILT LOCALIZATION MODEL SELECT
0 - 79 TWO TILTS MOVEMENT SEPERATELY
80 - 159 TWO TILTS WHOLE MOVEMENT
160 - 255 NO FUNCTION
20 PAN CONTINUOUS ROTATION
0 - 127 NO FUNCTION
128 - 189 FORWARDS ROTATION FAST-SLOW
190 - 193 NO FUNCTION
194 - 255 BACKWARDS ROTATION SLOW-FAST
21 LEFT TILT CONTINUOUS ROTATION
0 - 127 NO FUNCTION
128 - 189 FORWARDS ROTATION FAST-SLOW
190 - 193 NO FUNCTION
194 - 255 BACKWARDS ROTATION SLOW-FAST
3 Sixty 2R 24 Channel DMX Mode
Channel Value Function
12 LEFT PRISM ROTATION
128 - 189 FORWARD PRISM ROTATION
FAST - SLOW
190 - 193 NO ROTATION
194 - 255 BACKWARD PRISM ROTATION
SLOW - FAST
13 RIGHT PRISM/GOBO MACROS
0 - 31 OPEN
32 - 79 FROST
80 - 127 8 FACET PRISM
128 - 135 MACRO 1
136 - 143 MACRO 2
144 - 151 MACRO 3
152 - 159 MACRO 4
160 - 167 MACRO 5
168 - 175 MACRO 6
176 - 183 MACRO 7
184 - 191 MACRO 8
192 - 199 MACRO 9
200 - 207 MACRO 10
208 - 215 MACRO 11
216 - 223 MACRO 12
224 - 231 MACRO 13
232 - 239 MACRO 14
240 - 247 MACRO 15
248 - 255 MACRO 16
14 RIGHT PRISM ROTATION
0 - 127 PRISM INDEXING
128 - 189 FORWARD PRISM ROTATION
FAST - SLOW
190 - 193 NO ROTATION
194 - 255 BACKWARD PRISM ROTATION
SLOW - FAST
