Dimmer Manager software
Instruction Manual - page 55
Issue: 004
Lighting Technologies
Powering-up sequence
After all cables have been connected, we recommend the following power-up sequence: start at
the dimmers and work up towards the Dimmer Manager PC.
1. Dimmers
2. NETPORT XT
3. Hub/switch
4. Dimmer Manager PC
How can I find the IP address of a NETPORT XT
Each NETPORT XT leaves the factory with a factory-set fixed IP address. The standard factory
setting is 2.a.b.c where a.b.c are the three least significant bytes of the MAC address of the
NETPORT XT hardware.
The factory-set IP address is printed on the rear panel.
Alternatively, you can get a list of all the NETPORT XT present on the network by means of the
Scan Dimmers feature of Dimmer Manager. See Automatic discovery.
Note: NETPORT XT can be set to fixed IP addresses 2.1.2.21 or 192.168.0.21 by means of
specific internal settings (jumpers). For factory testing use only.
Note: the same applies to NETPORT.
Appendix E: touring racks with separate XLR5 “DMX only”
and “ADN only”
Many ADB Touring Dimmer Racks are fitted with two independent pairs of XLR5:
• one pair for “DMX only” (but with continuity of pin 4 and 5)
• one pair for “ADN only” (but with continuity of pin 2 and 3).
Subtlety: to obtain “DMX and ADN in the same DMX cable”, all you have to do is link DMX-only-
Out to ADN-only-In with a two-pair DMX cable.
Both remaining XLR5, DMX-only-In to ADN-only-Out now have DMX and ADN.
Example No. 1:
- NETPORT XT not used for DMX
- Tour rack 1 on universe A
- Tour rack 2 on universe B
- Both tour racks on ADN
Data cabling: daisy-chain from NETPORT XT to Rack 1 – ADN then to Rack 2 – ADN. The
sequence doesn’t matter.
DMX cabling: as usual.
Example No. 2:
- NETPORT XT not used for DMX
- Tour rack 1 on universe A and ADN
- MEMOPACK on universe A and ADN
Data cabling: daisy-chain from DMX console or splitter – NETPORT XT – Tour Rack1 DMX only
– Tour Rack 1 ADN only – MEMOPACK. The sequence doesn’t matter.
