KLEMANTIS AS 1000 RGBW
18
6. TECH DATA
4
00
(
15.75")
1000
(
39.37")
192
(
7.56")
271
(10.67")
KLEMANTIS AS1000 RGBW
ELECTRICAL SPECS
• Power supply: electronic auto-ranging
• Input voltage range: 100-240Vac
50/60 Hz
• Max power consumption: 300 VA at 230V/50Hz
POWER CONNECTION
• Power input: Neutrik PowerCON TRUE 1
• Power thru: Neutrik PowerCON TRUE 1
(daisy chain up to 5 x Klemantis AS1000)
DATA CONNECTION
• Control protocols: DMX512 / RDM / Art-Net 4
• Wireless control: optional (W-DMX™)
• Data IN connector: 5 pins XLR + RJ45
• Data OUT connector: 5 pins XLR
MECHANICAL SPECS
• Painting: black with epoxidic powder
• Net Weight: 15.9 Kg – 35.05 lbs
• Packed volume: 300 x 350 x 1170 mm
• Packed weight: 19 Kg
• Body: extruded aluminum and steel sheet
• Cooling system: forced ventilation with fans and heat-sink
• Max noise level: 24.6 dB(A) @ 1m
• IP protection rate: IP20
OPERATIONAL SPECS
• Any working position
• Min. distance to illuminated surface: 0.2m
• Ambient temp (min-max): -20°C / +40° C
• Maximum surface temperature: 90°
OPTICAL SPECS
• Source: 16 RGBW LED module featuring four colors: Red + Green +
Blue + White
• Color temperature: Tunable white ranging from 2500K to 8000K, with
perfect CCT
• Luminous flux: 3055 lumens
• Optics: FFL Asymmetric, proprietary optical design
FUNCTIONAL DATA
• Tungsten mode, to replicate the behavior of a tungsten lamp during
dimming from 0 to 100% and vice versa, including color temperature
adjustment.
• Tint correction: +/- green/magenta adjustments.
• 16-bit ultra-smooth dimming, with different dimming curves available.
• Smooth color transition between CTO and Color Point and Digital Filters
and Color Point.
• Gamma correction system.
• Color control: hue saturation luminosity (HSL), CMY, RGB and RAW
modes fully exploit the potential of the RGBW system; wide selection
of Digital filters (Color macros).
• High color stability and accuracy, also in tungsten mode, thanks to a
high resolution driver.
• Color consistency over time and temperature changes, thanks to
combined fixture calibration and a LED ageing compensation algorithm.
• Fixture to fixture color repeatability, thanks to tight wavelength binning
selection and 100% fixture calibration.
• Flicker-free, thanks to PWM frequency adjustment from 1 KHz to 50
KHz (10 Hz steps).
APPROVALS
• CE / ETL
PROVIDED WITH
• Neutrik PowerCON TRUE 1 power cable/bare ends (1.5m cable PVC
insulated 3X1.5mm)
• Omega bracket
