Dimmer Manager software
Instruction Manual - page 28
Issue: 004
Lighting Technologies
If you close the window before the Scan/Learn is finished, Dimmer Manager will ask you whether
you want to interrupt, or continue in the background.
Note: when you apply Scan Loads to several dimmer units, the tests will run simultaneously in
all the selected units. Testing a complete system takes about as long as testing its largest
dimmer unit.
Note: Scan Loads affects the lights on stage. When you apply Scan Loads to a dimmer unit, this
will set all its dimmers to Off, and will fade up each dimmer in turn. Partial testing of the
system, without affecting the other dimmers, is easy because you can select the dimmer
units to be Scanned.
Note: if a dimmer has been set to the NonDim law in the dimmer unit, then that dimmer will be
skipped by Scan Loads and the Scan value will show "NonDim". This is protecting the
load: the Scan Loads process fades up the dimmer level, and setting a local NonDim law
implies that you don’t want that load to be dimmed.
Learn Loads or Scan Loads of one dimmer
You may want to perform a re-Learn or re-Scan of one dimmer, without repeating the process
for the other dimmers.
• select the dimmer unit(s)
• Menu Bar > Dimmers > Command > Learn Loads
This opens the dialogue window "Learn Loads"
• select the dimmer you want to Learn (or Scan)
(to select more than one dimmer: keep CTRL depressed while selecting)
• click Learn (or Scan)
View Loads
View Loads does not test any dimmer. It shows the Learned values, the results of the latest Scan
Loads, and the comparison.
• Menu Bar > Dimmers > Command > View Loads
This opens a dialogue window “View Loads”.
Clear Loads
Clear Loads erases the reference values (Learned Loads) and the latest results (Scan Loads).
• select the dimmer units to be Cleared
• Menu Bar > Dimmers > Command > Clear > Clear Loads
• opens a pop-up window "Are you sure ?" to confirm: click Yes; to cancel: No
