EURODIM TWIN TECH
Page 71 sur 92
• if the load > 5.5.5KW (for a 5kW module)
• if the load is > 11KW (for a 10kW module)
3 - Displays "NO" in all other cases
OverCurrent
(per circuit)
Sinewave:
• Displays “low”: if the current is > 13 A
• Displays "average": if the current is > 16 A
• Displays "Severe": if the current is > 20 A
Thyristor with diag.: always "N/A"
Short-circuit
(per circuit)
Sinewave:
Displays "NO"
Displays "YES":
• The control is automatically set to zero
• After 2 mins, an actual control test is repeated and if the overload is "severe"
again, a second test is conducted. If the overload is still severe, a status
message is displayed at the bottom of the screen, requesting the user to set
all the DMX/ARTNET inputs of the circuit to zero for 30 secs.
Thyristor with diag.: always N/A
Temperature
Sinewave:
1 - Displays "OK"
2 - Displays “too high” => automatic control reduction until the temperature
now longer exceeds the threshold set
Note: The measure be different between the ½ circuits and the ¾ circuits
Thyristor with diag.: always N/A
Main voltage
Sinewave:
1 - Displays "OK"
Cases 2 and 3 do not trigger a module error as it is the main voltage that is
incorrect
2 - Displays "Too high"
3 - Displays “too low”
