EURODIM TWIN TECH
Page 70 sur 92
Thyristor (per circuit):
1 - Displays "OK" if the breaker is engaged
2 - Displays "TRIPPED" if the breaker has blown
Load (per circuit)
Sinewave & Thyristor with diag:
1 - Displays "N/A":
• The control is set to zero
• and/or the output voltage is too low
2 - Displays "NO":
• If the control value is > 0
• The output voltage is measured
• and the current is not measured
3 - Displays "YES"
• If the control is present
• And the output voltage and the output current is measured
Overloads
(per circuit)
Sinewave:
1 - Displays "light": if the voltage is > 13 A for 30 secs
2 - Displays "medium": if the current is > 16 A for 10 secs
• Here, the control decreases every 500 ms until the current reaches < 13
A
3 - Displays "Severe": if the current is > 20 A for 1 sec
• The control is automatically set to zero
• After 2 mins, an actual control test is repeated and if the overload is
"severe" again, a second test is conducted. If the overload is still severe,
a status message is displayed at the bottom of the screen, requesting the
user to set all the DMX/ARTNET inputs of the circuit to zero for 30 secs.
Thyristor with diag.:
1 - Displays “N/A” if the breaker has blown
2 - Displays "YES” if the breaker is OK and:
• If the load is > 3.5KW (for a 3kW module)
