ARTEX PRODUCTS / ACR ELECTRONICS, INC.
DESCRIPTION, OPERATION, INSTALLATION AND MAINTENANCE MANUAL
ELT 1000 (P/N: A3-06-2749-1)
Y1-03-0259 Rev. AC Company Confidential 25-62-33 Page 23 of 65
C. Antenna
1) Table 4 lists the antenna specifications of the ELT 1000.
PARAMETERS
CHARACTERISTICS
110-338/01
Tri-band
110-773
110-340
A3-06-2835
Style
Rod
Whip
Blade
Rod
Frequencies
121.5, 406 MHz
VSWR
121.5 MHz–2.0:1 Max.
406 MHz – 1.5:1 Max
Polarization
Vertical Monopole
Radiation Pattern
Omnidirectional
Impedance
(ohms)
50 Nominal
Weight
0.45 lbs
(0.20kg)
0.18 lbs
(0.08 kg)
1.40 lbs
(0.64 kg)
0.45 lbs
(0.20kg)
Coax Cable
RG-142 or RG-400 (>0.5dB <1 dB Insertion Loss)*
Connector
BNC Female
Dimensions
(Base to Tip)
15.5 in (394
mm)
15 in (381
mm)
7.75 in (197 mm)
15.5 in (394 mm)
Table 4 Antenna Specifications
NOTE: The ARTEX recommended coaxial cables Part No. 611-6013-04 (6 ft) and 611-6013-13 (12
ft) comply with the minimum and maximum cable insertion losses quoted above.
