ARTEX PRODUCTS / ACR ELECTRONICS, INC.
DESCRIPTION, OPERATION, INSTALLATION AND MAINTENANCE MANUAL
ELT 1000 (P/N: A3-06-2749-1)
Y1-03-0259 Rev. AC Company Confidential 25-62-33 Page 13 of 65
2. Model Description
A. ELT 1000
1) The ARTEX ELT 1000 is a type AF (Automatic Fixed) beacon, which transmits on 121.5 and 406 MHz.
2) The housing and mounting tray are made of impact-resistant polycarbonate-polyester plastic.
3) An installation kit, cockpit remote switch, coax cable, audible buzzer and fixed antennas are available.
3. Approvals
A. ELT
1) FAA TSO C126b, type AF
a) This article meets the minimum performance and quality control standards required by a technical
standard order (TSO). Installation of this article requires separate approval.
2) ETSO-C126a (EASA.IM.21O.10050368)
3) COSPAS-SARSAT TAC 251
4) For all other type approval information, please refer to the ARTEX web site at www.acrartex.com.
B. Battery
CAUTION: LITHIUM BATTERY SAFETY CONCERNS INCLUDE THE POSSIBILITY OF FIRE,
VENTING VIOLENTLY, AND VENTING OF TOXIC GASES.
1) The lithium battery packs used on the ARTEX ELT 1000 are certified under TSO C142a.
NOTE: The conditions and tests for TSO approval of this article are minimum performance
standards. Those installing this article, on or in a specific type or class of aircraft, must
determine that the aircraft installation conditions are within the TSO standards. TSO articles
must have separate approval for installation in an aircraft. The article may be installed only
according to 14 CFR part 43 or the applicable airworthiness requirements. Lithium cell and
battery safety concerns include the possibility of fire and venting of toxic gases.
2) If the battery is installed by a third party, it must be ascertained whether it is an ARTEX Authorized Service
center. To find an authorized service center, go to http://www.acrartex.com/where-to-buy/find-a-battery-
service-provider/
