| 46
• Ensure that the siren is installed out of hand’s reach (minimum 3 m
installation height).
• When choosing the installation location, ensure that the siren can be seen
and heard from a long distance.
• Pressing the tamper contact for the rst time activates the siren. Aer this,
if the tamper contact is triggered, the tamper alarm is triggered.
Please note further information on the wireless siren:
• Managing and adding components: Page 72
• Technical data: Page 115
9.3 Installation
Ax the drilling template provided for the
siren at the desired installation location.
Use a spirit level to ensure the drilling
template is straight. Drill holes in the
specied positions and insert the screw
anchors provided. Remove the drilling
template.
Attach the A-shaped bracket to the wall
using the screws.
Connect the power supply unit provided to the
siren and hook the sirens into the bracket from
above (click 1), then press it against the wall
(click 2).
Now tighten the small screw on the underside
of the bracket.
