Congratulations! You are now the owner of a top quality ABUS bicycle helmet. This
helmet has been produced under strict conditions and is certied according to the
following standards:
• Please read and follow these safety instructions. Non-observance of these instructions
could lead to fire, injury to persons and/or device damage!
• Keep packaging material away from children: Danger of suffocation!
• ABUS August Bremicker Söhne KG hereby declares that this helmet is Category II personal
protective equipment (PPE), and complies with Regulation (EU) 2016/425.
• ABUS August Bremicker Söhne KG hereby declares that the radio equipment type HYP-E,
Remote Control Indicator Light and Remote Control Brake Light (OxiBrake) is in
compliance with Directives 2014/53/EU and 2011/65/EU. The full Declaration of Conformity
can be found online at: docs.abus.com
• EN 1078:2012+A1:2012 – European standard for cyclists, skateboarders and inline skaters.
• This helmet has been certified by KIWA Nederland B.V., Wilmersdorf 50,
7327 AC Apeldoorn, The Netherlands, NB 0063.
Attention: Please note that no helmet is indestructible and will not prevent all head
injuries.
For the best possible protection, please observe the following guidelines:
1. Usage
This helmet is recommended as protective equipment for the following activities (g. A).
It is not suitable for the following activities (g. B).
Attention: Please note that it is necessary for children to remove their helmets before
entering playgrounds. This helmet should not be used by children while climbing or
doing other activities when there is a risk of strangulation/hanging if the child gets
trapped with the helmet.
2. Optimum fit
• The helmet should not be pulled too far down the forehead so that visibility is not
impaired.
• The forehead must be protected. The helmet should therefore not be pushed too far over
the back of the head.
• The helmet is correctly fitted when it sits horizontally on the head.
The prerequisite for your helmet to full a protective function is that it ts correctly. You
should therefore try out dierent sizes and choose the one that sits rmly and comfortably
on your head (g. C).
3. Adjustement of the head ring
Almost all ABUS helmets are available in three sizes.
Adjusting the helmet to the individual head size
can be achieved, depending on the type, with the
following easy to use tting systems.
4. Adjustment of the straps (g. Info 1)
When wearing the helmet for the rst time, please adjust the straps so that they meet taut-
ly and comfortably beneath the ears. The easily adjustable triangular locks on both sides,
with their optional fastener help you in doing so. The child proof lock must be engaged
properly, before rst use, with an audible “click” to prevent accidental displacement. Make
sure the chin-guard, which must be locked before every ride, doesn’t lie on the jaw-bone.
Aer adjustment, the overlapping straps can be secured with the strap clip. Should the
straps be too long, please cut them down to the required length and seal the ends with a
match ame to prevent fraying.
5. Switching the helmet light on and o (g. Info 2)
To switch on, briey press the On/O button on the back of the helmet once.
To switch o, press and hold the On/O button for 2 seconds until the switch-o animation
initiates switching o the helmet.
The Remote Control Brake Light and Remote Control Indicator Light are automatically
operational as soon as the helmet is switched on. This means that no separate switching
on/o is necessary.
6. Visor (g. Info 6.)
7. Charging
Open the charging port cover on the back of the helmet and plug the USB-C cable into the
charging port. During charging, the charging status is indicated by the centre area of the
rear light. As soon as the battery is fully charged, the light goes out. A full charge of the
helmet takes a maximum of 4 hours. Please do not use the helmet while charging.
Filter category Description Usage Symbol
ISO 12312-3:2022
0
Light tint
sunglasses
Very limited reduction of sunglare
Limited UV protection
IEC 60417-5955
1
Limited protection against sunglare
Moderate UV protection
ISO 7000-2948
2
General purpose
Sunglasses
Good protection against sunglare
Good UV protection
ISO 7000-2949
3
High protection against sunglare
Good UV protection
ISO 7000-2950
Please clean the lenses with mild soapy water. Drying should be done with a so cloth.
Note: Scratched lenses cannot provide adequate protection from the sun! Not suitable
for direct observation of the sun. Not suitable for protection against radiation from arti-
cial light sources, such as those used in solaria. The lter has a luminous transmittance
lower than 75% and higher than 8%. Not suitable for driving in twilight or at night.
