Chapter 22 Dashboard
PoE12-3PD User’s Guide
17
IP Address The PoE12-3PD needs an IP address for it to be managed over the network. The factory
default IP address is 192.168.1.1.
This field displays the PoE12-3PD’s current IP address.
Default Gateway The field displays the gateway that allows you to send or receive data traffic to or from a
different network than the one the PoE12-3PD is on.
Management Mode This field displays whether the PoE12-3PD is being managed by NCC.
• Standalone: When working in standalone mode, the PoE12-3PD is configured mainly
with its built-in Web Configurator. The PoE12-3PD is in standalone mode by default.
• Cloud: You can manage and monitor the PoE12-3PD through the NCC. It offers many
features to better manage and monitor not just the Zyxel Device, but your network as a
whole. See Section 19.4 on page 3 on how to switch your PoE12-3PD to Cloud mode.
System Uptime This field displays how long the PoE12-3PD has been running since it last restarted or was
turned on.
System Time This field displays the current date and time. The format is mm/dd/yyyy hh:mm:ss (UTC +
hh:mm).
Power-Up Mode This field displays the IEEE PoE standard of the power received from the UPLINK port. This
affects the available PoE usage for PDs. See Table 59 on page 2 to see more information on
PoE standard of the ports.
PoE Usage (Watt) This field displays the amount of power the PoE12-3PD is currently supplying to the
connected PoE-enabled devices and the total power the PoE12-3PD can provide to the
connected PDs.
Device Information
System Name This field displays the name used to identify the PoE12-3PD on the network.
Model Name This field displays the model name of the PoE12-3PD.
Serial Number This field displays the serial number of the PoE12-3PD.
MAC Address This field displays the MAC address of the PoE12-3PD.
Firmware Version This field displays the version number and date of the firmware the PoE12-3PD is currently
running.
Port Settings and Neighbor
Ports This identifies the Ethernet port on the PoE12-3PD.
Name This field displays the name you assigned to this port.
Link This field displays the current link speed (either 10M for 10 Mbps, 100M for 100 Mbps, or 1G
for 1 Gbps) and duplex mode (F for full duplex or H for half) for each connected port. It
displays Down for non-connected ports.
PoE State Slide the switch to the right to enable supplying PoE power to the PD.
Power-Up This field displays the IEEE PoE standard of the supplying power of each port.
Consuming Power
(W)
This field displays the amount of power the PoE12-3PD is currently supplying to the
connected PDs.
System Name This field displays the system name of the connected device.
IP This field displays the IP address of the connected device
MAC Address This field displays the MAC address of the connected device.
Device Registration Scan the QR code to go to the Nebula Mobile app and register your PoE12-3PD with NCC.
Table 67 Dashboard (continued)
LABEL DESCRIPTION
