Chapter 20 Hardware
PoE12-3PD User’s Guide
11
The following table describes the ports.
20.2 Grounding and Surge Protection
The PoE12-3PD is an outdoor device with built-in surge protection. However, it must be properly
grounded.
Grounding is a safety measure to direct excess electric charge to the ground. It prevents damage to
the PoE12-3PD, and protects you from electrocution. Any device that is located outdoors and
connected to this product must be properly grounded and surge protected. To the extent permissible
by your country’s applicable law, failure to follow these guidelines could result in damage to your PoE12-
3PD which may not be covered by its warranty.
Note: Qualified service personnel must ensure the building’s protective earthing terminals are
valid terminals.
Note: Note: The protective earthing conductor must be installed by a technician.
20.2.1 Grounding
1 Push down and slide out the device cover.
2 To help protect against lightning and electromagnetic interference, connect the green/yellow ground
cable to a grounding bar or on-site grounding terminal.
Table 65 Port Connections
LABEL DESCRIPTION
Port 1 / Port 2 / Port 3 Connect the ports to an Ethernet device, such as a PoE AP, IP camera or IP phone.
UPLINK Connect the port to a PoE switch or PoE injector with power source.
