ASI183 Manual
6
4. Camera technical specifications
Sensor
1″ CMOS IMX183CLK-J/CQJ-J
Diagonal
15.9mm
Resolution
20.18Mega Pixels 5496*3672
Pixel Size
2.4μm
Image area
13.2mm*8.8mm
Max FPS at full resolution
19FPS
Shutter
Rolling shutter
Exposure Range
32μs-2000s
Read Noise
1.6e @30db gain
QE peak
84%
Full well
15ke
ADC
12 bit or 10 bit
DDR3 buffer
256MB(Cooled)
Interface
USB3.0/USB2.0
Adapters
2″ / 1.25″ / M42X0.75 Uncooled
2″ / M42X0.75 Cooled
Protect window
AR window
Dimensions
Uncooled 62mm/Cooled 78mm
Weight
Uncooled 140g/Cooled 410g
Back Focus Distance
6.5mm
Cooling:
Regulated Two Stage TEC
Delta T
40°C - 45°C
(based on 30°C ambient temperature)
Cooling Power consumption
12V at 3A Max
Supported OS
Windows, Linux & Mac OSX
Working Temperature
-5°C—45°C
Storage Temperature
-20°C—60°
Working Relative Humidity
20%—80%
Storage Relative Humidity
20%—95%
