Names of Parts
5
Names of Parts
4
[EDIT] key
[ERASE] key
[INSERT/DELETE] key
[ENTER] key
[EXIT] key
[MUTE] key
[DRUM A] key (LED)
[DRUM B] key (LED)
[BASS] key (LED)
[SONG TRACK] key (LED)
[PAD FUNCTION] key
[POWER] switch
[DC IN] jack
[MIDI OUT] connector
[MIDI IN] connector
[CONTROL IN 1/2] jack
JAM slider
[JAM FUNCTION] key
(LED)
[ ] / [ ]keys
[ ] / [ ]keys
Display
* Keys and pads marked
(LED) contain an internal
LED that causes the
entire key to light up.
Pads 1 - 13 (LED)
[REPEAT/STEP] key
[R OUT / L/MONO OUT] jacks
[PHONES] jack
[LINE IN] jack
[SUB OUT 1/2] jacks
[DATA CARD] slot
SmartMedia card
Caution
Correct Wrong
[OUTPUT] dial
[VALUE] dial
[SONG] key
[PATTERN] key
[KIT] key
[UTILITY] key
[TEMPO] key (LED)
[ REC] (STEP REC) key (LED)
[ ] (PLAY) key (LED)
[ ] (STOP) key
[PAD BANK/OCTAVE] key
If the SmartMedia card is
inserted with wrong
orientation, it will not go
all the way into the slot.
Do not try to force the
card in, because this will
damage the card.
Names of Parts
Top Panel
Side Panel
Rear Panel
