Controls and Functions
5
ZOOM FIRE-30
◆
Input/preamplifier section
This section comprises the input jack and controls for adjusting distortion depth and tone.
(1) [INPUT] jack
Connect the electric guitar here, using a dedicated instrument cable.
(2) [VARIATION] key
(3) [DRIVE TYPE] knob
Select the simulated amp type and distortion (drive) type.
The [DRIVE TYPE] knob gives access to 11 types, and the [VARIATION] key provides further
variations (vintage/standard). The LED for the currently selected variation lights up.
(4) [GAIN] knob
Adjusts the input gain. Turning this knob up increases distortion depth.
(5) [BASS]/[MIDDLE]/[TREBLE] knobs
This is a 3-band equalizer that allows boost/cut in the low, medium, and high frequency range.
(1) (3)
(2) (4) (5) (6)
(7)
(8)
(9)
(10)
Controls and Functions
Input/preamplifier section
Patch section Effect section
Output/control section
