Controls and Functions
5
ZOOM FIRE-15
◆
Input/preamplifier section
This section comprises the input jack and controls for adjusting distortion depth and tone.
(1) [INPUT] jack
Connect the electric guitar here, using a dedicated instrument cable.
(2) [DRIVE TYPE] knob
Selects the simulated amp type and distortion (drive) type.
(3) [GAIN] knob
Adjusts the input gain. Turning this knob up increases distortion depth.
(4) [BASS]/[MIDDLE]/[TREBLE] knobs
This is a 3-band equalizer that allows boost/cut in the low, medium, and high frequency range.
(5) [LEVEL] knob
Adjusts the volume after passing the preamplifier.
(6) [BOOST] key
Setting this key to ON (LED lit) boosts the sound pressure level.
(1) (2)
(3) (4) (5)
(6)
(7)
Controls and Functions
Input/preamplifier section
Patch section Effect section
Output/control section
