ZOOM 708II BASS
24
MODULATION module, the effect type is
temporarily switched to P-PIT.
●
MOD
The effect type currently selected for the
MODULATION module is adjusted by the
pedal. Which parameter is controlled depends
on the effect type.
●
GAIN
The currently selected effect is adjusted by the
pedal. Which parameter is controlled depends
on the effect type.
●
REV
The effect type currently selected for the
DLY/REV module is adjusted by the pedal.
Which parameter is controlled depends on the
effect type.
●
VOL
The master volume is adjusted by the pedal.
●
SAMPLER
The sampler function is switched on/off by the
pedal. Pushing the pedal all the way down
toggles between sampler on ([PEDAL] LED lit)
and sampler off ([PEDAL] LED flashed).
Also if a module is currently off, selecting it
with the [PEDAL] key will cause its [PEDAL]
LED to light and the module will temporarily
come on. If a patch is stored in this condition,
the module will be stored as ON.
The actual parameter that is controlled by the
pedal depends on the effect type. For details, see
p. 33 – 38.
The above procedure for assigning a module/effect
type to the expression pedal can be carried out also
in edit mode.
3.
Press the [EDIT] key to activate the
edit mode.
4.
Use the MODULE [
E
]/[
R
] keys to
select the TOTAL module.
5.
Press the [EDIT] key once more.
The key lights up in green. In this condition,
parameter knobs 2 and 3 have the following
functions.
6.
Use parameter knobs 2 and 3 to set
the PDLMIN value (when pedal is fully
raised) and PDLMAX value (when
pedal is fully lowered). The setting
range for both values is 0 – 10.
When you operate parameter knob 2, the
indication "PDLMIN" appears on the display.
When you operate parameter knob 3, the
indication "PDLMAX" appears on the display.
The 0 – 10 value is shown on the [BANK/
PATCH] indicator.
Setting PDLMIN or PDLMAX to 0 means that
the parameter assigned to the pedal will be at
the minimum value. Setting PDLMIN or
PDLMAX to 10 means that the parameter
assigned to the pedal will be at the maximum
value.
When the 708II is in the default condition,
PDLMIN is set to 0 and PDLMAX is set to 10.
As the pedal is depressed, the parameter value
gradually increases from minimum to
maximum.
MAX=10
MIN=0
Lit
Parameter knob 2
Sets the value for the
fully raised position
of the pedal.
Parameter knob 3
Sets the value for the
fully lowered position
of the pedal.
HINT
Other Functions
