ZOOM 707II GUITAR
37
This effect tracks the picking action and controls filter
opening accordingly.
POSI
AF, bF
Selects connection point of MOD module.
• AF: After CABINET module
• bF: Before DRIVE module
TIME
1 – 30
Adjusts filter attack speed.
RANGE
1 – 10
Sets adjustable filter range.
Delay effect with a delay time of up to 500 milliseconds.
TIME
1 – 50
Adjusts delay time in 10-ms steps.
FB
0 – 10
Adjusts number of repeat cycles (feedback) for delay
sound.
MIX
0 – 30
Adjusts effect sound level.
Long delay effect (up to 2 seconds) with warm sound.
TIME
1 – 50
Adjusts delay time in 10-ms steps up to 1 second and in
100-ms steps up to 2 seconds.
FB
0 – 10
Adjusts number of repeat cycles (feedback) for delay sound.
MIX
0 – 30
Adjusts effect sound level.
This delay effect varies the delay time according to the
picking intensity.
SENS
1 – 50
Adjusts effect sensitivity.
FB
-10 – 10
Adjusts number of repeat cycles (feedback) for delay
sound.
BAL
0 – 30
Adjusts balance between direct sound and effect sound.
This is a combined tremolo and chorus effect.
TRMRAT
1 – 30
Adjusts tremolo speed.
CHORAT
1 – 30
Adjusts modulation speed of chorus effect.
CHOMIX
0 – 30
Adjusts chorus sound mix.
This is a combined ring modulator and vibrato effect.
RINRAT
1 – 30
Adjusts ring modulation effect frequency.
VIBRAT
1 – 30
Adjusts vibrato effect speed.
VIBDEP
0 – 10
Adjusts vibrato effect depth.
This is an automatic vibrato effect.
DEPTH
0 – 10
Adjusts effect depth.
RATE
1 – 30
Adjusts effect speed.
BAL
0 – 30
Adjusts balance between direct sound and effect sound.
Parameter 3
Parameter 2
Parameter 1
VIBE (Vibrato)
TYPE 20
Parameter 3
Parameter 2
Parameter 1
RINVIB (Ring Modulator + Vibrato)
TYPE 19
Parameter 3
Parameter 2
Parameter 1
TRMCHO (Tremolo + Chorus)
TYPE 18
Parameter 3
Parameter 2
Parameter 1
T-TRIP (Time Trip)
TYPE 17
Parameter 3
Parameter 2
Parameter 1
ECHO
TYPE 16
Parameter 3
Parameter 2
Parameter 1
DELAY
TYPE 15
Parameter 3
Parameter 2
Parameter 1
FILTER
TYPE 14
DLY/REV (Delay/Reverb) Module
This module comprises various spatial effects including delay and reverb.
This is a reverb effect which simulates the acoustics of a
concert hall.
This is a reverb effect which simulates the acoustics of a
room.
This is a reverb effect which simulates a spring type
reverb machine.
* Parameters for TYPE 1 - 3 are the same.
TIME
1 – 30
Adjusts reverb duration (reverb time).
TONE
0 – 10
Adjusts effect tone.
MIX
0 – 30
Adjusts reverb sound mix.
This is a monaural delay with a duration of up to 1.5
seconds.
When two amplifiers are used, this serves as a ping-
pong delay effect with a duration of up to 1.5 seconds.
When one amplifier is used, the effect is a mono delay.
* Parameters for TYPE 4 and 5 are the same.
TIME
1 – 99, 1.0 – 1.5
Adjusts delay time from 10 ms to 990 ms in 10-ms steps
(1 - 99), and over 1 second in 100-ms steps (1.0 - 1.5).
Parameter 1
PP-DLY (Ping-Pong Delay)
TYPE 5
MN-DLY (Mono delay)
TYPE 4
Parameter 3
Parameter 2
Parameter 1
SPRING (Spring Reverb)
TYPE 3
ROOM (Room Reverb)
TYPE 2
HALL (Hall Reverb)
TYPE 1
Effect Types and Parameters
