ZOOM 506 II BASS
2928
ZOOM 506 II BASS
PEDAL DEFRET (Pedal Defret)
Using the expression pedal (FP01/FP02) connected to the
CONTROL IN jack, the defret effect intensity can be adjusted.
PEDAL BASS SYNTH (Pedal Bass Synthesizer)
Using the expression pedal (FP01/FP02) connected to the
CONTROL IN jack, the mixing ratio of b2 effect sound and original sound
can be adjusted.
PEDAL OCTAVE (Pedal Octaver)
Using the expression pedal (FP01/FP02) connected to the
CONTROL IN jack, the mixing ratio of octaver effect sound and original
sound can be adjusted.
OCTAVE (Octaver)
This effect downshifts the sound by one octave and mixes it to the original
sound. Higher right-digit setting values result in a higher effect sound ratio.
OCTAVE > CHORUS (Octaver > Chorus)
This effect type is a serial connection of octaver and chorus. Higher right-
digit setting values result in stronger octaver sound. (Chorus intensity is
fixed.)
BASS SYNTH (Bass Synthesizer)
This effect creates the sound of a bass synthesizer. It is best suited for
playing single notes. You can select among nine patterns (b1 - b9) with
preset sound character and mixing balance.
• b1: Bass synthesizer with fat low end and multiple harmonics (only
effect sound is output)
• b2: Bass synthesizer with resonant filter (only effect sound is output)
• b3: Bass synthesizer with soft sound and few harmonics (only effect
sound is output)
• b4: b1 effect sound with a slight amount of original sound mixed in
• b5: b2 effect sound with a slight amount of original sound mixed in
• b6: b3 effect sound with a slight amount of original sound mixed in
• b7: b1 effect sound and original sound in 1:1 ratio
• b8: b2 effect sound and original sound in 1:1 ratio
• b9: b3 effect sound and original sound in 1:1 ratio
b
1
b
9
o
1
o
6
o
7
o
9
d
P
b
P
o
P
PITCH SHIFT (Pitch Shift)
This effect varies the pitch of the original sound. You can select one out of
nine preset pitch shift patterns (P1 - P9).
PEDAL PITCH DOWN (Pedal Pitch Down)
Original sound
Original sound
Original sound
Original sound
Using the expression pedal (FP01/FP02) connected to the
CONTROL IN jack, the pitch of the effect sound can be shifted over the
range of 0 to -1 octaves.
PEDAL PITCH UP (Pedal Pitch Up)
Using the expression pedal (FP01/FP02) connected to the
CONTROL IN jack, the pitch of the effect sound can be shifted over the range
of 0 to +1 octave.
OFF (Off)
Turns the MOD module off.
• P1/P2: A component shifted by 1 octave down is mixed to the original
sound. The mixing ratio differs for P1 and P2.
• P3/P4: A component shifted by a perfect fifth down is mixed to the
original sound. The mixing ratio differs for P3 and P4.
• P5/P6: A component shifted by a perfect fourth up is mixed to the
original sound. The mixing ratio differs for P5 and P6.
• P7/P8: A component shifted by 1 octave up is mixed to the original
sound. The mixing ratio differs for P7 and P8.
•
P9:
A slightly pitch-shifted component is mixed to the original
sound, resulting in a chorus with slight modulation.
Pitch of effect sound vs. original sound
P1/P2:
P3/P4:
P5/P6:
P7/P8:
P
1
P
9
P
d
P
U
o
F
Effect sound
Effect sound
Effect sound
Effect sound
Effect Types and Parameters
Effect Types and Parameters
