Names of Parts
3 ●
Connect the accessory AC adapter to the DC INPUT jack. The power to
the 3000B is ON when the AC adapter is plugged into a power outlet.
Adjust the volume of the musical instrument and the amplifier while
playing the instrument.
300mA
DC9V OUTPUT
(PHONES)
INPUT
REMOTE IN
SERIAL NO.
PHONES OUT
INPUT
REMOTE IN
OUTPUT
DC INPUT
RP01
PEDAL
SW
MODE
SELECT
MONITOR
STATUS
MODE DELECT
PEDAL-WAH ON/OFF(PEDAL SW)
DELAY MODE
(PEDAL SW TRIGGER)
RTM MODE
VOLUME ASSIGN
PEDAL-PITCH ON/OFF(PEDAL SW)
When using the optional remote
pedal RP01, use the remote
cable supplied with the RP01 to
connect the REMOTE OUT
jack of the RP01 to the
REMOTE IN jack of the 3000B.
Power for the remote pedal will
be supplied by the 3000B.
Other remote cables (RC05,
RC10) cannot be used.
A pair of stereo headphones can
be connected to the OUTPUT
(PHONES) jack. If the volume
level from the headphones is low,
use phones with low impedance.
When using the 3000B with one bass
guitar amplifier, make the connection
with a mono cable. For driving two
bass guitar amplifiers, a stereo Y
cable is required. The use of two
amplifiers will result in impressive
wide sound for stereo effects.
Headphones
AC adapter
Bas amplifiers
Bass
Getting Connected
Before Playing
STEP
1
Cut the power to the amplifier, turn the volume down to its minimum level, and
connect the 3000B correctly to the musical instrument and amplifier
STEP
2
Power up the 3000B.
STEP
3
Switch ON the power to the amplifier.
ADVANCED BASS EFFECTS PROCESSOR
After completing connection, the volume has to be adjusted according to the following procedure.
