!! English
!
!
4.! TECHNICAL SPECIFICATION
Modulator
Standard
DVB-T
Constellation
QPSK / 16QAM / 64QAM
Bandwidth
6 / 7 / 8 MHz
Carriers
2K / 8K
Guard Interval
1/4, 1/8, 1/16, 1/32
Code Rate
1/2, 2/3, 3/4, 5/6, 7/8
MER
35 dB
Frequency Range
50 ~ 860 MHz
Output Level
70 ~ 100 dBuV
Output Impedance
75!
Video
Input Format
CVBS/HDMI
Encoding Format
H.264
Input Resolution
576i PAL / 480i NTSC/ 1080p / 4K
Loop Out Resolution
Max to 4K
RF Out Resolution
Max to 1080p30
Connector
RCA/HDMI 2.0
Audio
Input Format
Stereo L/R channel
Encoding Format
MPEG-1 Audio Layer II
Connector
RCA
General
Power Source
DC 12V / 1.5A
Operating Temperature
0 ~ +50°C
Dimensions
212mm(L) " 121mm(W) " 33mm(H)
Weight
0.9Kg
Note:
1.! Since the modulator uses H.264 encoding, users need using DVB-T service which
supports
standard H.264 encoding for normal display.
2.! HD program which contains HDCP agreement protection will not play normally,
such as Blue-ray Disc and so on.
3. If the image and sound are not synchronous, please insert HDMI port again, it will
return to normal.
