3.2.3 Conguring the temperature setpoints

Since the appliance is equipped with 2 resistor stages, 2 dierent temperature setpoints can be congured.

"SP" corresponds to stage 1 and "SP2" to stage 2.

• Press the

key.

"SP" is displayed on the screen.

• Press the

or keys to set "SP" to the desired temperature setpoint.

• Press the

key to conrm the temperature setpoint "SP" and move on to conguring the

temperature setpoint "SP2".

• Press the

or keys to set "SP2" to the desired temperature setpoint.

• Press the

key to conrm the temperature setpoint "SP2" and return to the main screen (where

the measured water temperature is displayed).

Informaon: automac return to the main screen (where the measured water temperature is

displayed)

• When seng the temperature setpoints "SP" and "SP2", if no movement is detected on the

keypad for 15 seconds, the display automacally returns to the main screen.

Informaon: conguring the two temperature setpoints to the same value

• When the two temperature setpoints ("SP" and "SP2") are set to the same value, the two resistor

stages will operate simultaneously.

3.2.4 Stopping the audible alarm signal

If an error is detected on the appliance, the screen displays the

indicator, accompanied by an audible

signal.

• To stop the audible alarm signal, press any key on the keypad.

3.3 I Starng the appliance

• Set the lter pump to manual operaon to test the operaon of the heater and when rst bringing the

pool up to temperature (once the pool has reached the desired temperature, return to automac ltering),

• Check the ltraon circuit and heater body are vented,

• Check that the water ow rate is between 5 and 22m³/h. If the ow rate is greater than 22 m³/h, assemble

using a bypass,

• Set the 30 mA residual current circuit breaker, at the head of the line,

• Congure the temperature setpoints (see § "3.2.3 Conguring the temperature setpoints") on the digital

display thermostat so that heang is required (the temperature setpoint must be greater than the measured

water temperature),

• If the heater has been powered for more than 15 seconds, the heang outlet(s) will be simultaneously

acvated (indicator and/or steadily lit). Conversely, a me delay will be acve (indicator and/

or ashing), before being "steadily lit" when heang is acve (outlet 1 and/or 2 acvated).

• The temperature is regulated by degrees.

• The setpoint adjustment range is between 2° and 40°C.

• To check that the ltraon me is long enough:

- During the temperature rise phase, water circulaon must be connuous (24 hours/day),

- To maintain the temperature throughout the season, run "automac" circulaon for at least 12

hours/day (the longer the ltraon me, the greater the heang capacity)

3.4 I Checks to be carried out

The heater must stop operang when:

• The temperature set point is lowered,

• The regulaon system stops,

• Filtraon stops.
