8
2.3.3 Cable sizes
• Power cord size: for cables of a maximum length of 20 metres (calculaon basis: 5A/mm²), this must be
checked and adapted depending on the installaon condions.
Power
Current input Cable size
Single-phase
230V~ - 1L -
50/60Hz
Three-phase
400V~ - 3L -
50/60Hz
Single-phase
230V~ - 1L - 50/60Hz
Three-phase
400V~ - 3L - 50/60Hz
12kW 53A / 3 x 16 mm
2
3G16 / /
15kW 66A 22A 3 x 16 mm
2
3G16 5 x 6 mm
2
5G6
18kW / 26A / / 5 x 6 mm
2
5G6
21kW / 31A / / 5 x 10 mm
2
5G10
24kW / 35A / / 5 x 10 mm
2
5G10
2.4 I Opon connecons
2.4.1 "Remote "On/O" control" opon
• This opon allows the "remote On/O" funcon to be enabled by way of a switch installed remotely.
• To connect, couple the remote "On/O" switch (not provided) to terminals 1 - 2 using a power cord.
Connecng the "Remote "On/O" control" to a
single-phase appliance
Connecng the "Remote "On/O" control" to a
three-phase appliance
: Earth
N: Neutral
L: Phase
: Neutral phase
: Cable
: Power cord*
: Heater terminal block
: Switch box**
* See § "2.3.3 Cable sizes"
** Protecon with 30 mA residual current circuit breaker at the head of
the line.
EN
