10
2.3 I Operang
• Check that there are no tools or other foreign objects in the machine.
• The panel that provides access to the technical secon must be put in place.
• Set the valves as follows: valve B wide open, valves A, C, D and E closed
: water entry valve
: by-pass valve
: water exit valve
: water entry adjustment valve (oponal)
: water exit adjustment valve (oponal)
• An incorrect by-pass seng may cause the heat pump to malfuncon.
• Check that the hydraulic correcons are correctly ghtened and that there are no leaks.
• Check that the device is fully stable.
• Set the water circulaon running.
• Close valve B gradually so that the lter pressure is increased by 150g (0.150 bars).
• Open valves A, C and D fully then valve E by half (the air which has built up in the heat pump condenser and the
ltraon circuit will bleed out). If valves D and E are not present, open valve A wide and close valve C by half.
• Connect the power supply to the heat pump.
• If the heat pump is on standby, press
, for 3 seconds , appears for 2
seconds then
(dierent soware No. depending on the devices) for 3 seconds , and the water
and setpoint temperatures are displayed
, a 2 minute mer will start.
• Set the temperature you want ("setpoint" temperature).
Aer the start-up steps for your heat pump:
• Shut down the water circulaon temporarily (by stopping the ltraon or closing valve B or C) to check that you
device stops aer a few seconds (via the acvaon of the ow rate controller).
• Switch o the heat pump by pressing and holding
for 3 seconds and check that it stops.
2.4 I Addional user funcons
2.4.1 Adjusng the temperature setpoint
• Press to increase the temperature by 0.5 °C,
• Press to reduce the temperature by 0.5 °C.
The heat pump stops automacally when the pool reaches the required temperature.
2.4.2 Locking/unlocking the keyboard
Press and hold and for 3 seconds: or .
