1.4.2 "Heang priority" opon
• This funcon helps to keep the water temperature constant by checking the water temperature at regular me
intervals (minimum 5 minute cycle every 60 minutes) by ltraon pump control. The ltraon is kept operang if the
pool temperature is below the temperature requested.
• For the connecon, connect the ltraon mer to terminals 1 and 2 (dry contact, no polarity, maximum intensity 8A).
1
2
1- 2 : power for the ltraon pump power contactor coil
: ltraon mer
: power contactor (tripolar or bipolar) for the ltraon system pump motor
: separate cable for the "heang priority" funcon
: heat pump terminal unit
: fuse
1.4.1 "Alarm" opon
• This opon enables a relay to be connected to the alarm contact to indicate a fault by remote.
• For the connecon, connect the cables to terminals 5 and 6 (dry contact, no polarity, maximum intensity 2A).
: heat pump terminal unit
: alarm contact relay
: separate connecon cable
: fuse
1.4.3 Remote "on/o" control opon
• This opon enables the "on/o" buon funcon to be transferred via a switch installed by remote.
• For the connecon, remove the shunt between terminals 7-8 and connect the switch cable in place (potenal free
contact, no polarity, 220-240V ~ 50Hz).
• Acvate the command by pressing for 5 seconds when the regulaon is not on standby:
then
,
• Press for 3 seconds: ,
• Select "Yes" with , then validate by pressing : ,
• Press
to exit.
: heat pump terminal unit
: remote "on/o" switch
: separate connecon cable
