MagnaPool™ | Installation Manual
8.3.4 Heating Priority
When a filtration pump (single speed or variable
speed) is assigned and the heating priority function
is activated outside of the filtration timers, the
filtration pump will turn on for 5 minutes every 120
minutes in order to check water temperature.
NOTE: If a Zodiac
®
-compatible variable speed pump is
used, you can assign one of the ltration speeds
to the heating priority feature.
If the water temperature is lower than the setpoint
by -1°C, the heating system is activated and the
filtration pump stays on until the water temperature
reaches the desired setpoint.
If the water temperature is higher than the setpoint
by +1°C, the heating system is not activated and
the filtration pump turns off until the next cycle.
Section 9. Calibration and Priming
9.1 pH Sensor Calibration
The pH sensor may be calibrated in 1 point
calibration or 2 point calibration (pH 4 and pH 7); 2
point calibration is recommended.
1. Turn on power to the controller.
2. Turn off the pool pump and close valves as
necessary to isolate the cell and sensors.
3. Press .
4. Use to select “pH Setup” then press .
5. Use to select “pH Calibration”
then press .
6. Use to select “ 1 Point”, or “ 2 Points”,
then press .
7. Remove the pH sensor from the POD.
8. Insert the pH sensor into the
pH 7 buffer solution.
9. Press while “Start” is selected.
10. Press while “Go to Step 2” is selected.
11. Rinse the pH sensor with tap water.
12. Insert the pH sensor into the pH 4 buffer
solution.
13. Press while “Start” is selected.
14. Press while “Continue” is selected.
15. Press to exit.
<-PH SETUP
-ORP SETUP
-LOW MODE
MAIN MENU
<
-PH SETPOINT
-PH CALIBRATION
-ACID PUMP
-TEST DOSAGE
PH SETUP
<
-1 POINT
-2 POINTS
PH CALIBRATION
<
PH SENSOR INTO
BUFFER PH 7
START
STEP 1
PH 7 CALIBRATION
PROCEEDING
STEP 1
<
PH 7 CALIBRATION
COMPLETE
GO TO STEP 2
STEP 1
IN TAP WATER
RINSE SENSOR
<
PH SENSOR INTO
BUFFER PH 4
START
STEP 2
PH 4 CALIBRATION
PROCEEDING
STEP 2
<
PH 4 CALIBRATION
COMPLETE
CONTINUE
STEP 2
9.2 ORP Sensor Calibration
1. Turn on power to the controller.
2. Turn off the pool pump and close valves as
necessary to isolate the cell and sensors.
3. Press .
4. Use to select “ORP Setup” then press .
5. Use to select “ORP Calibration”
then press .
6. Remove the ORP sensor from the POD.
7. Insert the ORP sensor into the
470 mV buffer solution.
8. Press while “Start” is selected.
9. Press to exit.
<-ORP SETUP
-LOW MODE
-SLAVE MODE
MAIN MENU
<
-ORP SETPOINT
-ORP CALIBRATION
ORP SETUP
<
-BUFFER 470 MV
START
ORP CALIBRATION
<
PROCEEDING
ORP CALIBRATION
<
COMPLETE
ORP CALIBRATION
9.3 Setpoint(s)
Current setpoints are displayed on the Home
screen whenever the controller is ON.
<
PRODUCTION AUTO
PH=7.2
ORP=500
SET=7.0
SET=750
23:04 ON
9.3.1 Establish the pH Setpoint
Establishing the pH setpoint determines when acid
will be added to the system to decrease the pH of
the water.
1. Press .
2. Use to select “pH Setpoint”
then press .
3. Use to select value then press .
4. Press to exit.
