❶ Specicaons
1.1 I Descripon
or or
Heat Line Plus
Heat Line Plus without circulang pump
Bare Heat Line
1.2 I Technical specicaons
Heat Line 20 40 70
Power with primary circuit at 90°C (kW) 20 40 70
Power with primary circuit at 60°C (kW) 8.5 26 26
Power with primary circuit at 45°C (kW) 4 8 14
Primary circuit ow rate (m³/h) 0.9 1.7 3
Secondary circuit ow rate (m³/h) 10 15 20
Primary circuit head loss (bar) 0.015 0.02 0.03
Secondary circuit head loss (bar) 0.05 0.08 0.1
Primary connecon
Ø 26/34 female, screw type (Heat Line Plus and without circulang pump)
Ø 26/34 male, screw type (Bare Heat Line)
Secondary connecon PVC Ø50 or Ø63
Primary circuit operang temperature
(°C)
45 - 90
Secondary circuit operang temperature
(°C)
2 - 40
Primary circuit service pressure 200 000 Pa
Primary circuit maximum pressure 300 000 Pa
Absorbed power 33 W
Electrical characteriscs (Heat Line Plus and Heat Line without circulang pump)
Heat Line
20 40 70
Voltage
230V to a 2-pin+Earth socket
~ 50 Hz
Protecon rang IP44
Characteriscs of the circulang pump only
Heat Line Plus
20 40 70
Spacer 130 mm
Intensity 0.36 A
Power 33 W
