Page 6
Zodiac
®
Freerider
™
iQ Cordless Robotic Cleaner | Owner’s Manual
Section 2. Cleaner Specifications
2.1 General Specifications
The general specifications for the cleaner are as
follows:
WARNING
Only use the battery charger supplied with the cleaner.
Charging Station Supply
Voltage
100-240 VAC; 50/60 Hz
Supply Voltage 29.4 V DC
Battery Capacity 9.6 Ah
Operating Power 29.4 W
Cleaner Size (WxDxH) 41 x 42 x 28 cm
Weight of Cleaner 9.1 kg
Packed Weight 15.5 kg / FR1000 iQ
16.5 kg / FR2000 iQ
Filtration All-purpose filter canister
Cycle Lengths Variable programming
Charge Temperature Max 35°C
Min 5°C
Water Temperature
Range
Max 35°C
Min 13°C
Operating Depth Max 4 m
Min 40 cm
The cleaner is a double-insulated product.
Adouble-insulated electrical appliance is one which
has been designed in such a way that it does not
require a safety connection to ground. The basic
requirement for double-insulation is that no single
failure can result in dangerous voltage becoming
exposed so that it might cause an electric shock
and that this is achieved without relying on an
earthed (grounded) metal casing. Thisis achieved
by having two (2) layers of insulating material
surrounding live parts or by using reinforced
insulation. Therefore, devices having double-
insulated construction, such as this cleaner,
donotuse a grounded (three-prong) cord/plug.
2.2 Contents
The packaging should contain the following items:
• Freerider
™
Cleaner
• Charging Station
• Removal Hook
• Transportation Caddy*
• Remote Control*
* Model FR2000 iQ
*
*
Figure 1. Contents
2.3 Assemble the Charging Station
1. Insert the top of the charging station foot
(marked with a blue dot) into the top rear of
the charging station (also marked with a blue
dot). Push the lower part of the foot into the
lower cavity of the charging station until clip
issecure.
2. Attach the hook clip to either charging station
foot. Attach the hook to the clip.
3. Run cable through either foot cable slot.
FR1000 iQ
Cable slots
Figure 2. Assemble Charging Station
Refer to the trolley assembly document for
trolley assembly instructions.
