Page 11
Zodiac
®
Freerider
™
iQ Cordless Robotic Cleaner | Owner’s Manual
NOTE: Cycle interruption will occur with any usage of
remote control during a cleaning cycle. Cleaning
cycle will restart from the begining. Do NOT
leave remote fully submerged for extended
periods.
3.5 Removal
3.5.1 Lift System Retrival with Remote Control
The Lift System is designed to assist in retrieving
the cleaner from the pool. Lift System can be
activated at any time during or after a cleaning
cycle.
1. Place the end of remote control in the pool
and press Lift System to begin automated
procedure.
2. The cleaner will drive forward and up the
nearest wall it is facing. It will wait at the
waterline to be retrieved.
Figure 12. Cleaner Drives to Wall
3. When in reach, remove the cleaner from the
pool using the handle. The cleaner will quickly
expel water to allow for lighter, easier removal.
Figure 13. Remove Cleaner
3.5.2 Waterline Retrieval
1. At the end of the cleaning cycles (other than
Floor Only), the cleaner climbs and waits at
thewaterline.
2. If the cleaner is not retrieved after 30 seconds,
itmoves to a different wall.
NOTE: If the cleaner is not removed at the waterline, it
will return to the floor at the end of the cycle.
3. If not retrieved after 10 minutes, the cleaner
returns to the pool floor for retrieval with the
hook and pool pole.
4. If connected to the iAquaLink
®
app, you will
receive push notifications to your mobile
device alerting you to remove the cleaner.
5. Remove cleaner at the waterline by using the
handle and it will expel water to make it lighter.
Figure 14. Remove the Cleaner
3.5.3 Manual Retrieval
1. Attach the hook (stored on the charging
station) to a standard pool cleaning pole (not
included).
Figure 15. Removal Hook
2. Secure the hook on the cleaner handle. Bring
the cleaner to the waterline.
