12
2.3 I Installing the sensors (pH & pH/ORP, depending on model)
• Never wipe the sensor using a cloth or paper ssue, as this may damage it.
• A badly-installed sensor may give false readings and cause inappropriate operaon of the appliance.
Neither the manufacturer nor the appliance shall be liable in this event.
• Carefully unscrew the protecon tube from the sensor ( ). Keep the protecon tube for storing the sensor over
winter.
• Rinse the end of the sensor with tap water and shake o excess water ( ).
• Loosen the nut xed to the sensor holder ( ).
• Install the pH sensor and/or the ORP sensor (supplied) in the sensor holder so that the sensor located at the end
of the holder is always submerged in the water owing through the piping( ). Ensure that the cable is not
tangled.
• To avoid damage, sensor end must be located in the center of the pipe, not further.
• The sensor must always be installed vercally, or where necessary, at a maximum angle of 40°( ).
• Once the sensor is installed it can be connected to the BNC socket on the control box, see § “2.5.2. Connecng the
control box” ).
• The sensor must then be calibrated, see § “4.4 I Calibrang the sensors (pH or pH/ORP models)”.
pH
ORP
40°
EN
