5
1.2 I Technical specicaons
eXPERT
7 12 21 30 40
Operang water temperature 5 - 40°C
Volume of treated water (m³)
(temperate climate, 8h/day ltraon)
30 50 100 140 180
Nominal chlorine producon 7 g/h 12 g/h 21 g/h 30 g/h 40 g/h
Nominal output current 3.5 A 6 A 3.5 A 6 A 6.5 A
Fuse (5x20 mm) 1 A T 2 A T 2 A T 3.15 A T 4 A T
Recommended salt level (g/L)
5 5 4 4 4
Min-max: 4-10
Power supply voltage
230V
50-60 Hz
Electrical power 46 W 92 W 92 W 184 W 207 W
Protecon rang IPX5
Minimum ow rate required through
the cell (m³/h)
3 3 5 6 8
Maximum allowable pressure in the
cell
1 bar
Number of electrode plates 3 5 7 11 13
Cell connecon Ø63 mm (use Ø50mm PVC reducers for 50mm pipe)
Sensor type Combined, glass body Ø12 mm
pH measurement range 0.0 - 9.9 pH
pH measurement accuracy 0.01
Sensor tolerance 0-40°C, water speed ≤ 2 m/s
pH sensor calibraon Semi-automac in 2 points (pH 4 and pH 7)
ORP measurement scale 0 - 999 mV
ORP measurement accuracy 1 mV
ORP sensor calibraon Semi-automac at 1 point (470 mV)
Maximum counter pressure (injecon
point)
1.5 bar
Peristalc pump ow rate (pH) 1.5 L/h
Length of box-cell cable 1.5 m
Packaged net weight (kg) 9 11 13 15 17
